Mobile Razor Wire Security Barrier

The portable Mobile Razor Wire Security Barrier structure is firm and stable, and the operation is fast and simple. Rapid Deployment razor wire barrier can effectively implement isolation, traffic blockage and regional control. mobile security barrier for order to maintain social security order, ensure public safety.
Quantity:

Product Description

Mobile Razor Wire Security Barrier product introduction:

The portable Mobile Razor Wire Security Barrier structure is firm and stable, and the operation is fast and simple. It can effectively implement isolation, traffic blockage and regional control. In order to maintain social security order, ensure public safety, standardize and guarantee public security organs and their people's police to perform public security management duties according to law. positive effects.

 Mobile-Razor-Wire-Security-Barrier

Mobile Razor Wire Security Barrier product parameters:

1.Dimensions: diameter Φ900 × high 865mm (storage state), net: single group of snake complex telescopic blade steel barbed wire, diameter Φ800mm;

2, stretching length: 10m barrier size: 800mm, other accessories: support frame, fixed pile 4;

3, product weight: ≤ 58kg (with accessories), ≤ 37kg (without accessories). customizable



Mobile Razor Wire Security Barrier- Rapid Deployment blade gill net specifications:

Mobile barrier spiral razor concertina Model: blade gill net is divided into BTO and CBT

BTO includes BTO-10 BTO-18 BTO-22 BTO-28 BTO-30

CBT includes CBT-60 CBT-65

BTO-22 is the most commonly used model in China (other models can also be customized)



Barbed wire material: hot-dip galvanized, stainless steel plate, aluminum-clad steel. (304, 316)

pecification

(型号)

shape

Blade thick

(厚度)

Core diameter

(芯线)

Knife length

(刀长)

Blade width

(刀宽)

Knife distance

(刀距)

BTO-10


0.5±0.05

2.5±0.1

10±1

13±1

26±1

BTO-12


0.5±0.05

2.5±0.1

12±1

15±1

26±1

BTO-18


0.5±0.05

2.5±0.1

18±1

15±1

33±1

BTO-22


0.5±0.05

2.5±0.1

22±1

15±1

34±1

BTO-28


0.5±0.05

2.5

28

15

45±1

BTO-30


0.5±0.05

2.5

30

18

45±1

CBT-60


0.6±0.05

2.5±0.1

60±2

32±1

100±2

CBT-65


0.6±0.05

2.5±0.1

65±2

21±1

100±2



Mobile Razor Wire Security Barrier features:

The drum wire blade intercepting net adopts the professional protection grade snake complex type telescopic blade steel barb mesh structure. The metal blade adopts the molding process to combine with the steel ring, and the ring and the ring are connected by metal buckles, which are firm and reliable, and are detachable.

The razor wire can be stored in the barrel for easy transportation, transportation and transportation.



Mobile Razor Wire Security Barrier product advantages:

We upgrade the products in this product according to the market demand. The existing three groups are armed at the same time to solve the problem of the previous single group. The single-group barrier network is used for isolation and traffic blocking in general, to maintain social security order and ensure public safety. Wait.

Three sets of drums can also block the protection and isolation of vehicles and some important places.



Mobile Razor Wire Security Barrier Application:

Widely used in military facilities, airports, warehouses, prisons, enterprises and institutions fortification and border defense, riot, isolation and so on.
