Smart Electric Razor Wire Coil

Smart electric razor wire coil act as a great deterrent against unwelcomed guests, system will be invaded by alarms and floodlights through human or animal damage.
Even if the power supply line is cut off and the 5 volts generated by the exciter are non-lethal, the system is very safe and can operate in all weather conditions.
Availability:
Quantity:

Product Description

1,  the intruder alarm fence system can be integrated into a concertina coil fence, a razor barb with a fence, a razor mesh fence, and a traditional fence system.

The system will be invaded by alarms and floodlights through human or animal damage.

Even if the power supply line is cut off and the 5 volts generated by the exciter are non-lethal, the system is very safe and can operate in all weather conditions.

Smart-Electric-Razor-Wire-Coil2

2,  It is compact, easy to transport, and can be readily installed on walls and fences or used in pyramid barriers.

Install Wire-Cutting Barriers Concertina Wire

The need to prevent unauthorized access by unauthorized persons into the territory of protected sites allows for a spiral barrier concertina in enterprises of all sectors, both as a main technical means of protection, and in conjunction with electronic means of detection.

Smart-Electric-Razor-Wire-Coil

3,  The effectiveness and simplicity of mounting the barricades of Barbed Wire concertina make it possible to erect a secure physical barrier, both the permanent and temporary nature, with minimal cost.In a residential area practiced method of mounting the barricades on top of the fence, assembly takes place in three stages:

1. The stipulation concertina towers on the fence, and wire mounting spiral;

2. Laying in a spiral-formed bracket;

3. The wire spiral.

4. The installation recommendations:

When installing the fence, install brackets to the welds or nails on each column (the distance between the brackets should be 2-4 meters, the height of the fence exceeds 50 mm diameter roadblocks, the installation form and method can be attached according to the shape of the fence On the fence bracket.

The concertina line stretches the operating position and loads a 2 mm wire diameter at two points. When the first cycle of the next round of the limit spiral is installed, the second spiral wire of the extremely straight spiral has a diameter of 2 mm in two opposite regions.



Product Parameters:
Reference number CBT-65.
Thickness: 0.6 ± 0.05.
Wire diameter: 2.5 ± 0.1.
Barb length: 65 ± 2.
Barb width: 21 ± 1.
Barb spacing: 100 ± 2.
Outside diameter: 450 mm - 500 mm.
No of loops: 33 - 56.
Single coil.


Materials Type:
A: Stainless steel razor wire.
B: Zinc-coated razor wire.
Both bounded together by clips to make it more strength.
Galvanized wire as tie wire for concertina wire fence installation.

Items

(BWG)

Diameter mm

Output m/kg

Traction kg/mm2

Zinc coating Zn/m2

CAG08050K

8

4,19

9,2

45

90

CAG10050K

10

3,40

14,0

45

85

CAG12050K

12

2,77

21,1

45

70

CAG14050K

14

2,11

36,4

45

65

CAG16050K

16

1,65

59,5

45

45

CAG18050K

18

1,24

105,5

45

45

CAG20000K

20

0,89

204,8

45

45



Product Features:

It is compact, easy to transport, and can be readily installed on walls and fences or used in pyramid barriers.

Install Wire-Cutting Barriers Concertina Wire

Easy to install and good protection effect.



Product Advantages:

The effectiveness and simplicity of mounting the barricades of Barbed Wire concertina make it possible to erect a secure physical barrier, both the permanent and temporary nature, with minimal cost.In a residential area practiced method of mounting the barricades on top of the fence, assembly takes place in three stages:

1.The stipulation concertina towers on the fence, and wire mounting spiral;

2.Laying in a spiral-formed bracket;

3.The wire spiral.


Application:

Safety protection of sites, communities, railways, airports, and important production facilities.

Smart-Electric-Razor-Wire-Coil4Rapid Deployment Barrier


   Razor Wire Installation Accessories

SUN Security offers the following tools for installing Razor Wire, including heavy duty bolt cutters, cable tie ratchets, clip applicators and handling hooks.

Razor-Wire-installation-accessories
